VS1 Operations and Maintenance Manual Operating the transmitter
Page 2-14 Issue 3.1 2013-10-01
User Settings - Scheduler Set up scheduler page 2-157
User Settings - Audio Processor Set audio processor to none or Orban Inside. page 2-165
Local/Remote Select local or remote control of the transmitter. page 2-90
View Status - View Alarms View all active transmitter alarms. page 2-28
View Status - View Log View the transmitter’s events log, including alarms,
commands, etc.
page 2-28
View Status - Clear Log Clear the transmitter’s events log. page 2-28
View Status - View Meters View the levels of various transmitter parameters,
including forward power, reflected power, PA
voltage, PA current and low level dc supply
voltages.
page 2-50
View Status - View SW Versions View the versions of installed software -
Reset Alarms Initiate an attempt to reset all alarms controlled by
latched protection circuits.
page 2-90
System Settings - Calibration Set calibration values or run calibration routines for
various parameters (e.g., TCXO offset, forward/
reflected power, program input levels, etc.).
page 2-99
System Settings Edit various transmitter system settings (see other
System Settings options in this table).
page 2-101
System Settings - Thresholds Factory set; no user adjustments required. -
System Settings - ARM
Watchdog
Enable, disable or force a reset of the ARM
watchdog feature.
page 2-102
System Settings - Console
Select
Factory set; no user adjustments required. -
System Settings - RF Drive
Source
Select either internal or external exciter. page 2-103
System Settings - ARM Reset Initiate a reset of the exciter/control PWB’s ARM
processor.
page 2-103
Table 2.1: Front Panel UI Screens
UI Screen Function See Page
