Controls/Features
Quadrant 2 – Display
Messages
Description Flash (Yes/No) Warning Indicator
Association
Electrical Fault (Priority 1 or 2) (1) Message is displayed when EGC requests the Red
warning indicator.
(2) Message is displayed when EGC requests the Yellow
warning indicator.
Yes (1) Red warning indicator
(2) Yellow warning
indicator
Check Trans Message is displayed when transmission needs to be
serviced.
Yes Yellow warning indicator
Trans Temp Message is displayed when transmission turns on
the Yellow warning indicator. Not available with all
transmissions.
Yes Yellow warning indicator
Gen Trns Flt Message is displayed when transmission turns on Red
Stop, MIL, or PROTECT, or the Yellow Warning indicator
without the conditions to display Check Trans, Trans Temp,
Trans Oil Life, Trans Oil Filter, or Trans Service. Not
available with all transmissions.
Yes Yes (see description)
Trans Oil Life Message is displayed when transmission oil needs
changed. Not available with all transmissions.
Yes No
Trans Oil Filter Message is displayed when transmission oil filter needs
changed. Not available with all transmissions.
Yes No
Trans Service Message is displayed when transmission needs service.
Not available with all transmissions.
Yes No
DPF Ash Service Required Message is displayed when diesel particulate filter ash
level requires service/cleaning.
Yes No
See Visor For Info Message is displayed indicates the particulate trap
indicator must be on or must flash.
Yes Yes (see description)
3879634R1 65
