Controls/Features
Quadrant 2 – Display
Messages
Description Flash (Yes/No) Warning Indicator
Association
Stop Engine Message is displayed when Red Stop indicator is
illuminated. MaxxForce® engine only.
Yes Red warning indicator
Warn Engine (Priority 1 or 2) (1) Message is displayed when MaxxForce, or MaxxForce®
11/13 ECM turn on the Red warning indicator.
(2) Message is displayed when MaxxForce, or MaxxForce®
11/13 ECM requests the Yellow warning indicator and not
the Red warning indicator.
Yes (1) Red warning indicator
(2) Yellow warning
indicator
Stop Hybrid Message is displayed when Hybrid system turns on and
requests the Red warning indicator.
Yes Red warning indicator
Check Engine Message is displayed when ECM requests the Yellow
warning indicator and not the Red warning indicator.
Yes Yellow warning indicator
HV Batt Off-Line Message is displayed when Hybrid system battery is off
line.
Yes No
Check Hybrid Message is displayed when Hybrid system turns on the
Yellow warning indicator while conditions for “HV Batt
Off-Line” message are not met.
Yes Yellow warning indicator
Low Engine Oil Level Message is displayed when engine oil level is less than
or equal to 80%.
Yes No
Change Engine Oil Message is displayed when engine oil change is detected
as necessary.
Yes No
Water in Fuel Message is displayed when water in fuel is present. Yes No
Refuel Message is displayed when fuel level is low. MaxxForce®
11 and 13 engines only.
Yes No
High Fuel Temp Message is displayed when fuel temp is high. MaxxForce®
11 and 13 engines only.
Yes No
64 3879634R1
