Controls/Features
Quadrant 2 – Display
Messages
Description Flash (Yes/No) Warning Indicator
Association
DRV Reward Increasing No No
DRV Reward Decreasing No No
VSL Ovrd Active No No
VSL Ovrd Expiring No No
Blank screen, available only when engine rpm less than
or equal to 325 RPM, or vehicle speed less than 2 mph
(3 km/h).
No No
Calibrate Compass Message is displayed when vehicle speed is less than
2 mph (3 km/h) and the operator has not requested
“Calibrate Compass” in the current ignition cycle.
No No
End Calibration Message is displayed when vehicle speed is less than 2
mph (3 km/h) and the operator has requested “Calibrate
Compass” in the current ignition cycle.
No No
Calibration Ended Message is displayed when vehicle speed is less than 2
mph (3 km/h) and the operator has requested “Calibrate
Compass” in the current ignition cycle.
No No
Declination Zone Message is displayed only when vehicle speed is less than
2 mph (3 km/h).
No No
Warning Messages
In addition to the Diagnostic Trouble Codes (DTC), the digital
display will display a warning message whenever an Engine
indicator is illuminated. This warning message will be toggled
with the normal DTC as follows:
Yellow Warning indicator: WARN ENGINE message
Red Stop indicator: Stop Engine message
The following chart provides the warning messages that are
displayed along with corresponding Instrument panel gauge
cluster indicators.
3879634R1 67
