NEC 535 - TTY Settings

Setting Name Setting Entry
Server URL Enter the synchronization server’s URL.
Server Login Enter your user name and password provided by the server provider.*
IP address Enter the IP address of the server in numeric values only, e.g.,
“000.00.000.00”.
Proxy address** Enter the IP address of the Proxy server in numeric values only, e.g.,
“000.00.000.00”.
Proxy Login** Enter the user name and password provided for the proxy server address.*
Phonebook Path Enter the relative path of the phonebook in the server. Begin with “./”,
e.g.,”./contact/personal”.
ToDo list Path Enter the relative path of the ToDo/tasks in the server. Begin with “./”, e.g.,
“./contact/tasks”.
Scheduler Path
Enter the relative path of the Scheduler in the server. Begin with “./”, e.g.,
“./contact/scheduler”.
HTTP Login**
Enter the user name and password for HTTP authentication.*
* The user id and password are case sensitive.
** The configuration is only mandatory if the server provides the feature. Only one
authentication may be used, either proxy or HTTP. The NEC 535M wireless phone cannot
operate with both types of authentication turned On.
TTY Settings
* Press MENU (Main), 1, 9, and 2 to display the TTY settings screen.
Press 1 to activate or 2 to deactivate the TTY mode.
The TTY device cable is attached to the wireless phone’s hands-free accessory port.
O The TTY default is Off
mode.
O TTY is an abbreviation for
teletypewriter and text
telephony--equipment that
employs interactive text
based communications
through the telephone
network.
65
