3. Setting Up Windows Server 2008 R2
Express5800/R320c-E4, R320c-M4, R320d-E4, R320d-M4 Installation Guide (Windows Server 2008)
(3) Data Disk Dual Configuration Procedure
Follow the procedure below to configure dual data disk for the slots 1 to 7.
Note
The following shows how to configure dual disk for the slot 1. If you want to configure the
dual disk for slot 2 to slot 7, read "slot 1" as the slots you want to make dual configuration
and perform the procedure.
1. Insert a disk for the dual configuration into the slot 1 of PCI Module 10.
If a disk is already mounted, this procedure is not necessary. Go to step 4.
2. From Start, select Control Panel, Administrative Tools and start Computer Management. On the
tree in the left pane, click Disk Management.
If the inserted disk is indicated as Not Initialized in the right pane, right-click the disk and initialize it.
Important
•
system may be displayed, but there is no need to reboot it. Select Restart Later
and close the popup window.
• Disk may become offline when RDR is set. In this case, use "Disk Management"
to make it online.
3. From Start, select All Programs then RDR and click RDR Utility to start RDR Utility.
To Next Page
