3. Setting Up Windows Server 2008 R2
Express5800/R320c-E4, R320c-M4, R320d-E4, R320d-M4 Installation Guide (Windows Server 2008)
89
Chapter 1 Installing OS
Important
• If the system is rebooted during synchronization, the process cannot be
completed. Do not restart the system until the synchronization is completed.
• When the system is halted without shutting down Windows properly
due to
forced shutdown or others, the entire area of the partition on the synchronized
disks will be resynchronized after the system is restarted.
Synchronization completed
DISK ACCESS LED
RDR Utility
Op State: State Status
Source disk Green (Blinking) Online –
Destination disk Green (Blinking) Online –
RDR Virtual Disk – Duplex None
Tips
DISK ACCESS LED is lit green only when hard disk drive is accessed.
If no access is made, the LED seems to be unlit.
