NEC Express5800/T71f - Page 57

45
Paramete
r
Description Option
SATA Controller When enabled, the SATA controller will
function normally.
[Enabled]
Disabled
SATA Mode Selection Select the on chip SATA type.
IDE: When set to IDE, the SATA controller
disables its RAID and AHCI functions and
runs in the IDE emulation mode. This is not
allowed to access RAID setup utility.
RAID: When set to RAID, the SATA controlle
r
enables both its RAID and AHCI functions.
You will be allows access the RAID setup
utility at boot time.
A
CHI: When set to AHCI, the SATA controller
enables its AHCI functionality. Then the RAID
function is disabled and cannot be access
the RAID setup utility at boot time.
IDE
RAID
[ACHI]
SATA Test Mode Enable/Disable SATA Test Mode. Enabled
[Disabled]
A
ggressive LPM Support Enable/Disable Aggressive Link Power
Management feature.
[Enabled]
Disabled
SATA Controller Speed Indicates the maximum speed that the SATA
controller can support.
[Default]
Gen1
Gen2
Gen3
