Software Feature Mask
Configuration
Press [Enter] for configuration of advanced
items.
Serial SATA Port 0/1/2/3/4/5 Displays the installed HDD devices. Press
[Enter] to view the information of installed
HDD devices
Software Preserve (for Serial
SATA Port 0/1/2/3/4/5)
Display the software preserve status for
Serial SATA Port 0/1/2/3/4/5.
Port 0/1/2/3/4/5 Enable/Disable Port 0/1/2/3/4/5. [Enabled]
Disabled
Hot Plug (for Serial SATA Port
0/1/2/3/4/5)
Enable/Disable Hot Plug support for Serial
TA Port 0/1/2/3/4/5.
Enabled
[Disabled]
External SATA (for Serial SATA
Port 0/1/2/3/4/5)
Enable/Disable External SATA support for
Serial ATA Port 0/1/2/3/4/5.
Enabled
[Disabled]
SATA Device Type Configure the SATA Device Type. SATA Device Type
[Hard Disk Drive]
Solid State Drive
Spin Up Device (for Serial SATA
Port 0/1/2/3/4/5)
On an edge detect from 0 to 1, the PCH
starts a COM reset initialization to the device.
Enabled
[Disabled]
RAID 0/ RAID 1/ RAID 10/ RAID 5Enable/Disable RAID 0/1/10/5 feature. [Enabled]
Disabled
Intel Rapid Recovery Technology Enable/Disable the Intel Rapid Start
Technology (IRSTe) function. The IRSTe
enables your system to get up and running
faster from even the deepest sleep, saving
time and power consumption.
[Enabled]
Disabled
OROM UI and BANNER Enable/Disable OROM UI and BANNER
feature.
[Enabled]
Disabled
HDD Unlock When this item is enabled, the HDD
password unlock in the OS is enabled.
[Enabled]
Disabled
LED Locate When this item is enabled, the LED/SGPIO
hardware is attached and ping to locate
feature is enabled on the OS.
[Enabled]
Disabled
IRRT Only on eSATA
When this item is enabled, only IRRT
volumes can span internal and eSATA drives.
If disabled, then any RAID volume can span
internal and eSATA drives.
[Enabled]
Disabled
Smart Response Technology Enable/Disable Intel Smart Response
Technology.
[Enabled]
Disabled
OROM UI Delay Configure OROM UI Delay. [2 Seconds]
4 Seconds
6 Seconds
8 Seconds
