SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 10
Server Configuration
1 Base Models
Product Name / Description
Part Number
NEC Express5800/R120h-2M 8x 2.5-inch Drive Model
No processor, no RAM, no HDD, no ODD, no Rail, no Power Supply Unit.
Including : Front Bezel, 8x 2.5-inch Drive Cage, 1st Riser Card Kit, Standard Fan Kit
N8100-2562F
NEC Express5800/R120h-2M 8x 3.5-inch Drive Model
No processor, no RAM, no HDD, no ODD, no Rail, no Power Supply Unit.
Including : Front Bezel, 8x 3.5-inch Drive Cage, 1st Riser Card Kit, Standard Fan Kit
N8100-2564F
NEC Express5800/R120h-2M 24x 2.5-inch Drive Model
No processor, no RAM, no HDD, no ODD, no Rail, no Power Supply Unit.
Including : Front Bezel, 24x 2.5-inch Drive Cage, 1st Riser Card Kit, High Performance Fan Kit
N8100-2563F
NEC Express5800/R120h-2M 12x 3.5-inch Drive Model
No processor, no RAM, no HDD, no ODD, no Rail
Including : Front Bezel, 12x 3.5-inch Drive Cage, 1st Riser Card Kit, High Performance Fan Kit
N8100-2565F
NOTE:
 The base model must be ordered with a processor kit, a memory kit, a power supply kit and Rail.
2 Processors
Available sockets: 2
Category
Product Name / Description
Part Number
Bronze 3100
Xeon Bronze 3104 Processor Kit
Intel® Xeon ® Bronze 3104 (1.70 GHz, 6C/6T, 8.25MB, TDP 85W)
N8101-1191 (1st)
N8101-1192 (2nd)
Xeon Bronze 3106 Processor Kit
Intel® Xeon ® Bronze 3106 (1.70 GHz, 8C/8T, 11MB, TDP 85W)
N8101-1193 (1st)
N8101-1194 (2nd)
Silver 4100
Xeon Silver 4108 Processor Kit
Intel® Xeon ® Silver 4108 (1.80 GHz, 8C/16T, 11MB, TDP 85W)
N8101-1195 (1st)
N8101-1196 (2nd)
Xeon Silver 4110 Processor Kit
Intel® Xeon ® Silver 4110 (2.10 GHz, 8C/16T, 11MB, TDP 85W)
N8101-1197 (1st)
N8101-1198 (2nd)
Xeon Silver 4112 Processor Kit
Intel® Xeon ® Silver 4112 (2.60 GHz, 4C/8T, 8.25MB, TDP 85W)
N8101-1199 (1st)
N8101-1200 (2nd)
Xeon Silver 4114 Processor Kit
Intel® Xeon ® Silver 4114 (2.20 GHz, 10C/20T, 13.75MB, TDP 85W)
N8101-1201 (1st)
N8101-1202 (2nd)
Xeon Silver 4116 Processor Kit
Intel® Xeon ® Silver 4116 (2.10 GHz, 12C/24T, 16.50MB, TDP 85W)
N8101-1203 (1st)
N8101-1204 (2nd)
Gold 5100
Xeon Gold 5115 Processor Kit
Intel® Xeon ® Gold 5115 (2.40 GHz, 10C/20T, 13.75MB, TDP 85W)
N8101-1205 (1st)
N8101-1206 (2nd)
Xeon Gold 5118 Processor Kit
Intel® Xeon ® Gold 5118 (2.30 GHz, 12C/24T, 16.50MB, TDP 105W)
N8101-1207 (1st)
N8101-1208 (2nd)
Xeon Gold 5120 Processor Kit
Intel® Xeon ® Gold 5120 (2.20 GHz, 14C/28T, 19.25MB, TDP 105W)
N8101-1209 (1st)
N8101-1210 (2nd)
Xeon Gold 5122 Processor Kit
Intel® Xeon ® Gold 5122 (3.60 GHz, 4C/8T, 16.50MB, TDP 105W)
N8101-1211 (1st)
N8101-1212 (2nd)
Gold 6100
Xeon Gold 6126 Processor Kit
Intel® Xeon ® Gold 6126 (2.60 GHz, 12C/24T, 19.25MB, TDP 125W)
N8101-1213 (1st)
N8101-1214 (2nd)
Xeon Gold 6128 Processor Kit
Intel® Xeon ® Gold 6128 (3.40 GHz, 6C/12T, 19.25MB, TDP 115W)
N8101-1215 (1st)
N8101-1216 (2nd)
Xeon Gold 6130 Processor Kit
Intel® Xeon ® Gold 6130 (2.10 GHz, 16C/32T, 22MB, TDP 125W)
N8101-1217 (1st)
N8101-1218 (2nd)
Xeon Gold 6132 Processor Kit
Intel® Xeon ® Gold 6132 (2.60 GHz, 14C/28T, 19.25MB, TDP 140W)
N8101-1219 (1st)
N8101-1220 (2nd)
Xeon Gold 6134 Processor Kit
Intel® Xeon ® Gold 6134 (3.20 GHz, 8C/16T, 24.75MB, TDP 130W)
N8101-1221 (1st)
N8101-1222 (2nd)
Xeon Gold 6136 Processor Kit
Intel® Xeon ® Gold 6136 (3 GHz, 12C/24T, 24.75MB, TDP 150W)
N8101-1223 (1st)
N8101-1224 (2nd)
Xeon Gold 6138 Processor Kit
Intel® Xeon ® Gold 6138 (2 GHz, 20C/40T, 27.50MB, TDP 125W)
N8101-1225 (1st)
N8101-1226 (2nd)
