SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 32
8 Other Add-in Components
Power Supply
Category
Product Name / Description
Part Number
1 PSU
Required
Up to 2 PSU
500W Hot Plug Power Supply
1 x 500 Watt 80 PLUS® Platinum
N8181-159
800W Platinum Hot Plug Power Supply
1 x 800 Watt 80 PLUS® Platinum
N8181-160
800W Titanium Hot Plug Power Supply
1 x 800 Watt 80 PLUS® Titanium
NOTE:
- Support 200 VAC inlet only
N8181-161
1600W Hot Plug Power Supply
1 x 1600 Watt 80 PLUS® Platinum
NOTE:
- Support 200 VAC inlet only
N8181-162
800W -48VDC Hot Plug Power Supply
1 x 800 Watt 80 PLUS® Platinum
NOTE:
- Support -48 VDC inlet only
- This is make-to-order product.
N8181-163
NOTE:
 Minimum one power supply kit must be installed.
 The power units must be the same to configure redundancy.
Available Power Supplies
See the table below for available power supplies based on the number of drives, the number and type of processors, and the type
and number of DIMMs.
24x2.5-inch Drive Model and 12x3.5-inch Drive Model
Number of
Processors
Type of Processor
Type of
DIMMs
Number of
DIMMs
Available Power Supply
1CPU
Processor with 150 Watt or less
RDIMM
-
800W, 1600W
64GB LRDIMM
-
800W, 1600W
128GB LRDIMM
-
1600W
Processor with 160 Watt or more
-
-
1600W
2CPU
Processor with 85 Watt
RDIMM
Up to six
800W, 1600W
Seven or more
1600W
LRDIMM
-
1600W
Processor with 105 Watt or more
-
-
1600W
 128GB LRDIMM requires 1600W power supply.
8x2.5-inch Drive Model (without Optional Drive Cage) and 8x3.5-inch Drive Model (without
Optional Drive Cage)
Number of
Processors
Type of Processor
Type of DIMMs
Number of
DIMMs
Number of PCI
Cards
Available Power
Supply
1CPU
Processor with 150 Watt or
less
RDIMM
Up to six
-
500W, 800W,
1600W
Seven or
more
-
800W, 1600W
64GB LRDIMM
-
-
800W, 1600W
128GB LRDIMM
-
-
1600W
Processor with 165 Watt or
more
RDIMM
-
-
800W, 1600W
64GB LRDIMM
-
-
800W, 1600W
128GB LRDIMM
-
-
1600W
