SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 33
2CPU
Processor with 115 Watt or
less
RDIMM
-
-
800W, 1600W
64GB LRDIMM
Up to 14
-
800W, 1600W
15 or more
-
1600W
128GB LRDIMM
-
-
1600W
Processor with 125 Watt
and 130 Watt
RDIMM
Up to 16
-
800W, 1600W
17 or more
-
1600W
64GB LRDIMM
Up to 12
Up to 6
800W, 1600W
7 or more
1600W
13 or more
-
1600W
128GB LRDIMM
-
-
1600W
Processor with 140 Watt
and 150 Watt
RDIMM
Up to 12
Up to 4
800W, 1600W
5 or more
1600W
13 or more
-
1600W
64GB LRDIMM
Up to 8
Up to 4
800W, 1600W
5 or more
1600W
9 or more
-
1600W
128GB LRDIMM
-
-
1600W
Processor with 165 Watt or
more
-
-
1600W
NOTE:
 128GB LRDIMM requires 1600W power supply.
 Number of PCI Cards do NOT include a dedicated RAID card or a dedicated LOM controller.
8x2.5-inch Drive Model (with Optional Drive Cage) and 8x3.5-inch Drive Model (with
Optional Drive Cage)
Number of
Processors
Type of Processor
Type of
DIMMs
Number of
DIMMs
Number of PCI
Cards
Available Power
Supply
1CPU
-
-
-
-
800W, 1600W
2CPU
Processor with 85 Watt
RDIMM
Up to 12
-
800W, 1600W
13 or more
-
1600W
LRDIMM
-
-
1600W
Processor with 105 Watt
RDIMM
Up to 6
Up to 6
800W, 1600W
7 or more
1600W
7 or more
-
1600W
LRDIMM
-
-
1600W
Processor with 115 Watt or
more
-
-
-
1600W
NOTE:
 128GB LRDIMM requires 1600W power supply.
 Number of PCI Cards do NOT include a dedicated RAID card or a dedicated LOM controller.
8x2.5-inch Drive Model and 8x3.5-inch Drive Model with GPU installation
Number of
Processors
Type of Processor
Type of
DIMMs
Number of
DIMMs
Number of PCI
Cards
Available Power
Supply
1CPU
-
-
-
-
800W, 1600W
2CPU
Processor with 115 Watt or
less
RDIMM
Up to 12
-
800W, 1600W
13 or more
-
1600W
64GB LRDIMM
Up to 6
-
800W, 1600W
7 or more
-
1600W
128GB LRDIMM
-
-
1600W
Processor with 125 Watt and
130W
RDIMM
Up to 6
Up to 6
800W, 1600W
7 or more
1600W
7 or more
-
1600W
LRDIMM
-
-
1600W
