SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 37
10 Factory Server Setting Service
Memory RAS Settings
If you need to change the BIOS settings for the memory RAS feature at the factory, select the appropriate configuration service.
Product Name / Description
Memory Mirroring Mode Configuration Service
Setup option to change the Memory RAS of BIOS menu to Memory Mirroring Mode
Memory Sparing Mode Configuration Service
Setup option to change the Memory RAS of BIOS menu to Memory Sparing Mode
NOTE:
It is an option only for factory setup
Single Rank Memory (N8102-708/-709) does not support Memory Mirroring Mode Configuration Service (NESV16-013)
11 Add-on Components
17-inch LCD Console Drawer
Product Name / Description
17-inch LCD Console Drawer (8port)
17-inch LCD, US 83-keys Keyboard, Optical mouse, 8 port KVM switch,
1U height
Switch Unit Connection Cable Set (USB, 1.8m)
1.8 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
Switch Unit Connection Cable Set (USB, 3m)
3 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
Switch Unit Connection Cable Set (USB, 5m)
5 m, 1 x 15-pin mini D-sub to 1 x 15-pin mini D-sub / 1 x 4-pin USB A
17inch LCD Console Unit 1U
17-inch LCD, US 83-keys Keyboard, Optical mouse, 1U height,
4-pin USB B to 4-pin USB A cable 2 m, PS/2 Y-splitter cable 2m, 15-pin
mini D-sub VGA cable 2 m
17inch LCD Console Drawer (1port)
17-inch LCD, US 103-keys Keyboard with 10-key, Touch pad with
3-button, 1U height, 4-pin USB B to 4-pin USB A cable 1.8 m, Two PS/2
cable 1.8 m, 15-pin mini D-sub VGA cable 1.8 m
Keyboard Unit (JP)
JP 108-keys Keyboard with 10-key for N8143-108F 17inch LCD Console
Drawer (1port)
Keyboard Unit (UK)
UK 104-keys Keyboard with 10-key, for N8143-108F 17inch LCD
Console Drawer (1port)
NOTE:
Keyboard of N8143-105F/-106F does not have 10-key.
Order Switch Unit Connection Cable Set as same number of sets as servers to be connected to. (max 8 servers)
