SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 21
RAID Controller for Standard PCI Slot
Category
Product Name / Description
Part Number
Storage Controller
RAID Controller (RAID 0/1)
RAID 0/1/5/10 and SAS HBA mode, 0MB, Int. 8, PCIe 3.0 x8, SAS
12Gb/s, SATA 6Gb/s
N8103-195
RAID Controller (2GB, RAID 0/1/5/6)
RAID 0/1/5/6/10/50/60, 2GB, Int. 8, PCIe 3.0 x8, SAS 12Gb/s, SATA
6Gb/s
N8103-201
Battery Backup
Battery Backup Unit
Lithium-ion Battery for N8103-190/-191/-196/-201 RAID controller.
1 battery provides power to all RAID controller.
N8103-198
Expander Card
SAS Expander Card
PCI card form factor, Int. 36, SAS 12Gb/s, SATA 6Gb/s
NOTE:
- The card is required when you install the number of SAS drives that
exceeds the number of the internal ports of a RAID controller.
N8116-51
Cable
Internal SAS/SATA Cable
NOTE:
Cable for RAID controller (PCI slot) to front Drive Cage and Expander Card.
K410-378(00)
NOTE:
 The RAID controller must be installed after shipment.
 One battery backup unit must be installed per system.
 N8103-195 supports RAID5. If higher performance is needed, choose RAID controller with cache memory.
Internal Drives
2.5-inch SATA Hard Disk Drives
Category
Product Name / Description
Part Number
512e Sector
2TB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 2 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm, 512e sector
N8150-545
NOTE:
 512e sector drives are not available for VMware ESXi 6.0 system.
 All drives within a RAID array should be of the same capacity.
 To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of
becoming multiple hard drives failure during the RAID rebuilding process.
2.5-inch SATA Solid State Drives
Category
Product Name / Description
Part Number
Read Intensive
DWPD ≈ 1
240GB Hot Plug 2.5-inch SATA SSD
1 x 240GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive
N8150-743
480GB Hot Plug 2.5-inch SATA SSD
1 x 480GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive
N8150-744
960GB Hot Plug 2.5-inch SATA SSD
1 x 960GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive
N8150-745
1.92TB Hot Plug 2.5-inch SATA SSD
1 x 1.92TB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive
N8150-746
3.84TB Hot Plug 2.5-inch SATA SSD
1 x 3.84TB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Read Intensive
N8150-747
Value Endurance
DWPD ≈ 3
240GB Hot Plug 2.5-inch SATA SSD
1 x 240GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance
N8150-739
480GB Hot Plug 2.5-inch SATA SSD
1 x 480GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance
N8150-740
960GB Hot Plug 2.5-inch SATA SSD
1 x 960GB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance
N8150-741
1.92TB Hot Plug 2.5-inch SATA SSD
1 x 1.92TB SATA SSD, 2.5-inch, 6Gb/s, 512n sector, Value Endurance
N8150-742
NOTE:
 All drives within a RAID array should be of the same capacity.
