SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 36
 The USB Memory Kit cannot be installed if M.2 SATA Solid State Drives are installed.
 To use VMware vSAN, combination of vSAN certified hardware is required.
 If you are using VMware vSAN and cannot boot from USB Memory Kit, please order M.2 SATA SSD.
Power Cable for GPU
Product Name / Description
Part Number
Graphics Card Power Cable (8Pin. Type A)
Power cable for video card (PCIe 8Pin)
K410-386(00)
Graphics Card Power Cable (8Pin. Type B)
Power cable for video card (CPU 8Pin)
K410-387(00)
Graphics Card Power Cable (8+6Pin)
Power cable for video card (8Pin + 6Pin)
K410-388(00)
Graphics Card Power Cable (6+6Pin)
Power cable for video card (6Pin + 6Pin)
K410-391(00)
NOTE:
 To install GPU cards, the riser card with a power connector for GPU, High Performance CPU Heatsink, and High Performance Fan
kit must be installed. Refer to PCI Riser Card /PCI Card, High performance CPU heatsink, and Fans in detail
 Cable varies depending on the GPU card installed. Please check the specifications of the GPU card and select the cable.
 For default factory configuration
