SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 34
Processor with 140 Watt and
150 Watts
RDIMM
Up to 6
Up to two
800W, 1600W
Three or more
1600W
7 or more
-
1600W
LRDIMM
-
-
1600W
Processor with 165 Watt or
more
-
-
-
1600W
NOTE:
 128GB LRDIMM requires 1600W power supply.
 Number of PCI Cards do NOT include a dedicated RAID card or a dedicated LOM controller.
Guideline of Maximum Power Consumption
See the following table for the guideline of the maximum power consumption based on the TDP and Input voltage. The actual
maximum power consumption varies depend on the type of processor while the TDP of processor is the same.
200VAC Input
CPU TDP
8 x 2.5-inch
24 x 2.5-inch
8 x 3.5-inch
12 x 3.5-inch
85 Watt
991W / 992VA
1036W / 1038VA
983W / 984VA
1013W / 1015VA
105 Watt
1048W / 1049VA
1093W / 1094VA
1039W / 1041VA
1070W / 1071VA
115 Watt
1045W / 1047VA
1100W / 1101VA
1046W / 1047VA
1077W / 1078VA
125 Watt
1094W / 1097VA
1150W / 1152VA
1096W / 1097VA
1127W / 1128VA
130 Watt
1086W / 1088VA
1141W / 1142VA
1087W / 1088VA
1118W / 1119VA
140 Watt
1134W / 1135VA
1189W / 1191VA
1135W / 1136VA
1166W / 1167VA
150 Watt
1153W / 1154VA
1208W / 1209VA
1153W / 1155VA
1184W / 1186VA
165 Watt
1201W / 1202VA
1254W / 1255VA
1152W / 1154VA
1183W / 1184VA
200 Watt
1270W / 1271VA
1326W / 1329VA
1217W / 1217A
1244W / 1247VA
205 Watt
1270W / 1271VA
1326W / 1329VA
1217W / 1217A
1244W / 1247VA
NOTE:
 This table shows maximum power consumption with 64GB LRDIMM.
High Performance CPU Heatsink
Product Name / Description
Part Number
High Performance CPU Heatsink Kit
Including two high performance CPU heat sink
N8101-1286
NOTE:
 The kit is required if you need to replace the standard CPU Heatsink.
Type of CPU Heatsink
The Heatsink attached varies depending on the processor type.
CPU
Type of CPU Heatsink
130W or higher TDP CPU, Intel® Xeon® Processor Platinum 8156, Gold 6128,
and Gold 5122
High Performance CPU Heatsink
Others
Standard CPU Heatsink
