SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 5
Technical Specification
Specification
Model
R120h-2M
8x 2.5-inch
Drive Model
24x 2.5-inch
Drive Model
8x 3.5-inch
Drive Model
12x 3.5-inch
Drive Model
Part Number
N8100-2562F
N8100-2563F
N8100-2564F
N8100-2565F
Processor
Type
Intel® Xeon® Processor
Bronze 3104(6C/6T, 1.70 GHz, 8.25MB, TDP 85W)
Bronze 3106(8C/8T, 1.70 GHz, 11MB, TDP 85W)
Silver 4108(8C/16T, 1.80 GHz, 11MB, TDP 85W)
Silver 4110(8C/16T, 2.10 GHz, 11MB, TDP 85W)
Silver 4112(4C/8T, 2.60 GHz, 8.25MB, TDP 85W)
Silver 4114(10C/20T, 2.20 GHz, 13.75MB, TDP 85W)
Silver 4116(12C/24T, 2.10 GHz, 16.50MB, TDP 85W)
Gold 5115(10C/20T, 2.40 GHz, 13.75MB, TDP 85W)
Gold 5118(12C/24T, 2.30 GHz, 16.50MB, TDP 105W)
Gold 5120(14C/28T, 2.20 GHz, 19.25MB, TDP 105W)
Gold 5122(4C/8T, 3.60 GHz, 16.50MB, TDP 105W)
Gold 6126(12C/24T, 2.60 GHz, 19.25MB, TDP 125W)
Gold 6128(6C/12T, 3.40 GHz, 19.25MB, TDP 115W)
Gold 6130(16C/32T, 2.10 GHz, 22MB, TDP 125W)
Gold 6132(14C/28T, 2.60 GHz, 19.25MB, TDP 140W)
Gold 6134(8C/16T, 3.20 GHz, 24.75MB, TDP 130W)
Gold 6136(12C/24T, 3 GHz, 24.75MB, TDP 150W)
Gold 6138(20C/40T, 2GHz, 27.50MB, TDP 125W)
Gold 6140(18C/36T, 2.30 GHz, 24.75MB, TDP 140W)
Gold 6142(16C/32T, 2.60 GHz, 22MB, TDP 150W)
Gold 6144 (3.50 GHz, 8C/16T, 24.75MB, TDP 150W)
Gold 6146 (3.20 GHz, 12C/24T, 24.75MB, TDP 165W)
Gold 6148(20C/40T, 2.40 GHz, 27.50MB, TDP 150W)
Gold 6150(18C/36T, 2.70 GHz, 24.75MB, TDP 165W)
Gold 6152(22C/44T, 2.10 GHz, 30.25MB, TDP 140W)
Gold 6154(18C/36T, 3GHz, 24.75MB, TDP 200W)
Platinum 8153(16C/32T, 2 GHz, 22MB, TDP 125W)
Platinum 8156(4C/8T, 3.60 GHz, 16.50MB, TDP 105W)
Platinum 8158(12C/24T, 3GHz, 24.75MB, TDP 150W)
Platinum 8160(24C/48T,2.10 GHz, 33MB, TDP 150W)
Platinum 8164(26C/52T, 2GHz, 35.75MB, TDP 150W)
Platinum 8168(24C/48T, 2.70 GHz, 33MB, TDP 205W)
Platinum 8170(26C/52T, 2.10 GHz, 35.75MB, TDP 165W)
Platinum 8176(28C/56T, 2.10 GHz, 38.50MB, TDP 165W)
Platinum 8180(28C/56T, 2.50 GHz, 38.50MB, TDP 205W)
Gold 6134M(8C/16T, 3.20GHz, 24.75MB, TDP 130W)
Gold 6140M(18C/36T, 2.30 GHz, 24.75MB, TDP 140W)
Gold 6142M(16C/32T, 2.60 GHz, 22MB, TDP 150W)
Platinum 8160M(24C/48T, 2.10 GHz, 33MB, TDP 150W)
Platinum 8170M(26C/52T, 2.10 GHz, 35.75MB, TDP 165W)
Platinum 8176M(28C/56T, 2.10 GHz, 38.50MB, TDP 165W)
Platinum 8180M(28C/56T, 2.50 GHz, 38.50MB, TDP 205W)
Number of Processors
1 or 2
Chipset
Intel® C621 Chipset
Memory
Type
DDR4-2666 Registered DIMM (8/16/32GB)
DDR4-2666 Load Reduced DIMM (64/128GB)
Standard Capacity
0 GB
Maximum Capacity
3 TB (24 x 128 GB)
Memory protection
ECC, x4 SDDC, x4 DDDC, Memory Mirroring, Memory Sparing
Internal Storage
Standard Capacity
0 GB
Disk Controller
SATA : 6Gb/s, RAID 0/1/5/6/10/50/60 (Optional)
SAS: 12 Gb/s, RAID 0/1/5/6/10/50/60 (Optional)
Hot Plug
Supported
Optical Disk Drive
Optional
-
Optional
-
Optical Drive Bays
1
-
1
-

NEC Express5800 Specifications

General

Processor	Intel Xeon
Storage	HDD/SSD
RAID Support	Yes (varies by model)
Power Supply	Redundant PSU options (varies by model)
Form Factor	Rackmount, Tower
Network	Gigabit Ethernet
Operating System Support	Windows Server, Linux
