SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 14
Xeon ® Gold 5100 series excluding Xeon ® Gold 5122 Processor
Xeon ® Silver 4100 series
2400 MHz
Xeon ® Bronze 3100 series
2133 MHz
Maximum Available Memory
See the table below for the maximum memory size that you can actually use on your system.
Operating Systems
Maximum Memory Size
Supported by Operating
Systems
Maximum Available Memory
Microsoft Windows Server 2012 R2 Standard
1
Microsoft Windows Server 2012 R2 Datacenter
1
4 TB
3 TB
Microsoft Windows Server 2016 Standard
1
Microsoft Windows Server 2016 Datacenter
1
24 TB
3 TB
Red Hat Enterprise Linux 7
12TB
3 TB
VMware ESXi 6.0
2
6 TB
3 TB
VMware ESXi 6.5
3
12 TB
3 TB
1
The maximum available memory size of Hyper-V systems is below:
- Windows Server 2012 R2 : 4 TB
- Windows Server 2016 : 24 TB
2
Up to 4 TB of the main memory is available to each virtual machine.
3
Up to 6 TB of the main memory is available to each virtual machine.
4 Internal Storage
Drive Bay Configuration
Choose appropriate drive model and optional drive cages in accordance with the type and number of the drive you want to install.
List of the number that Internal Drives can be mounted
Category
Front Cage
Rear Cage
Middle Cage
(Built in
standard Riser
Card )
Inside the
server
(Mounted on
Standard Riser
Card
1,2
)
8x 2.5-inch
Drive
Cage
1
Standard :
8x 2.5-inch SAS/SATA Drive
Expansion:
・8x2.5-inch SAS/SATA Drive
(Up to 1)
・Internal DVD Drive Kit (Up to 1)
Standard: -
Expansion:
2x2.5-inch SAS/SATA
Drive (Up to 3)
Standard: -
Expansion: -
Standard:
2xM.2 SATA
SSD
5
24x
2.5-inch
Drive
Cage
2
Standard:
24x2.5-inch Drive
Expansion: -
8x 3.5-inch
Drive
Cage
3
Standard :
8x3.5-inch SAS/SATA Drive
Expansion:
2x2.5-inch SAS/SATA Drive
(Up to 1)
Standard: -
Expansion:
・2x2.5-inch SAS/SATA
Drive (Up to 3)
・3x3.5-inch SAS/SATA
Drive (Up to 1)
Standard: -
Expansion:
4x3.5-inch
SAS/SATA Drive
(Up to 1)
12x
3.5-inch
Drive
Cage
4
Standard:
12x3.5-inch SAS/SATA Drive
Expansion: -
1
Up to 24 2.5-inch Drive Cage can be mounted
2
Up to 30 2.5-inch Drive Cage can be mounted.
3
Up to 15 3.5-inch Drive Cage can be mounted.In addition, one 2x 2.5-inch Drive Cage can be mounted.
4
Up to 19 3.5-inch Drive Cage can be mounted.In addition, one 2x 2.5-inch Drive Cage can be mounted.
5
Up to two M.2 SATA SSDs can be installed using the standard 1st riser card. However, you cannot install M.2 SATA SSD in the
optional 1st riser card. Also, it is impossible to connect RAID controller to M.2 SATA SSD.
