SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 6
Model
R120h-2M
8x 2.5-inch
Drive Model
24x 2.5-inch
Drive Model
8x 3.5-inch
Drive Model
12x 3.5-inch
Drive Model
Standard Disk Drive Bays
8
24
8
12
Expansion Slots
Standard
Total: 5 slots available
1 PCIe 3.0 x16 (x16 connector)
2 PCIe 3.0 x8 (x8 connector)
1 PCIe 3.0 x8 (x8 connector) for a dedicated RAID card
1 PCIe 3.0 x8 (x8 connector) for a dedicated LOM controller
* The slot mix changes by installing an optional riser card.
Video
Controller (VRAM)
Integrated in Server Management Controller (16MB)
Resolution
640x480, 800x600, 1,024x768, 1,280x1,024, 1,600x1,200, 1,920x1,200
Interfaces
Front
1x USB3.0
1x USB2.0 (BMC)
1x USB3.0
1x USB2.0
(BMC)
1x DisplayPort
-
Rear
2x USB3.0, 1x VGA (15-pin mini D-sub), 1x Management LAN connector
(RJ-45), 4x Data LAN connector (RJ-45), 1x Serial (9-pin mini D-sub,
Optional)
Internal
2x USB3.0, 2x SATA 2.0
Redundant Fan
Standard, hot plug
Redundant Power Supply
Optional, hot plug
Power Supply
1-2 x 500 Watt, 800 Watt, 1600 Watt 80 PLUS® Platinum certified hot
plug PSU
500Watt, 800 Watt : 100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
800Watt, 1600 Watt : 200-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Dimensions (W x D x H )
445.5 x 679.4 x 87.3 mm
17.5 x 26.7 x 3.4 in (2U)
445.5 x 730.2 x 87.3 mm
17.5 x 28.7 x 3.4 in (2U)
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 35° C / 50° to 95° F, 8 to 90%
Non-Operating: -30° to 60° C / -22° to 140° F, 5 to 95%
Regulatory and Safety
FCC, UL/cUL, CB, CE, Mexico (CoC), RCM, RoHS, WEEE
Operating Systems
Microsoft® Windows Server® 2012 R2 Standard
Microsoft® Windows Server® 2012 R2 Datacenter
Microsoft® Windows Server® 2016 Standard
Microsoft® Windows Server® 2016 Datacenter
Red Hat Enterprise Linux 7.3 or later
VMware ESXi™ 6.0 Update 3
VMware ESXi™ 6.5 Update 1
