SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 28
- Twinax cable can be installed.
25GbE
Dual Port 25GBASE SFP+ LOM Card
Cavium 45604
PCIe 3.0(x16)
NOTE:
- N8104-190 SFP+ Module is required to connect with an optical cable.
- Up to 2 SFP+ Modules can be installed.
- Twinax cable can be installed
N8104-177
Adapter
1GbE
Dual Port 1000BASE-T Adapter
Broadcom BCM5720 Gigabit Ethernet Controller
PCIe 2.0(x1)
N8104-178
Dual Port 1000BASE-T Adapter
Intel Ethernet Controller I350
PCIe 2.0(x4)
NOTE:
- Network cables with RJ-45 plug covers cannot be used.
N8104-180
Quad Port 1000BASE-T Adapter
Broadcom BCM5719 Gigabit Ethernet Controller
PCIe 2.0(x4)
NOTE:
- Network cables with RJ-45 plug covers cannot be used.
N8104-179
Quad Port 1000BASE-T Adapter
Intel Ethernet Controller I350
PCIe 2.0(x4)
NOTE:
- Network cables with RJ-45 plug covers cannot be used.
N8104-181
10GbE
Dual Port 10GBASE-T Adapter
QLogic 57810S
PCIe 2.0(x8)
N8104-182
Dual Port 10GBASE-T Adapter
Cavium QL41401,
PCIe3.0(x8)
N8104-183
Dual Port 10GBASE-T Adapter
Intel X550-AT2,
PCIe3.0(x4)
N8104-184
Dual Port 10GBASE SFP+ Adapter
QLogic 57810S
PCIe 2.0(x8)
NOTE:
- N8104-189 SFP+ Module is required to connect with an optical cable.
- Up to 2 SFP+ Modules can be installed.
- Twinax cable can be installed
N8104-185
Dual Port 10GBASE SFP+ Adapter
Intel Ethernet Controller X710
PCIe 3.0(x8)
NOTE:
- N8104-189 SFP+ Module is required to connect with an optical cable.
- Up to 2 SFP+ Modules can be installed.
- Twinax cable can be installed
N8104-186
25GbE
Dual Port 25GBASE SFP28 Adapter
Cavium QL41401,
PCIe3.0(x8)
NOTE:
- N8104-190 SFP+ Module is required to connect with an optical cable.
- Up to 2 SFP+ Modules can be installed.
N8104-187
SFP
Module
10GbE
SFP+ Module (10G-SR)
1 x SFP+ Module
N8104-189
25GbE
SFP28 Module (25G-SR)
1x SFP28 Module
SFP28 can be connected to 25G BASE adapter
NOTE:
- It is not factory installation option.
N8104-190
QSFP28 Module (100G-SR4)
1 x QSFP28 Module
QSFP28 can be connected to 25G BASE adapter
N8104-191
NOTE:
