SYSTEM CONFIGURATION GUIDE – NEC Express5800/R120h-2M
NEC Corporation Revision 5.0 – January 2018 30
 Only one SAS JBOD Enclosure can be connected to one RAID controller.
 4Kn sector drives are not supported with the RAID controller.
 One battery backup unit must be installed per system.
 To configure a large-capacity RAID array, it is recommended to configure in RAID 6 or RAID 60 in order to minimize the risk of
becoming multiple hard drives failure during the RAID rebuilding process.
 It is recommended to set RAID array configuration drives less than eight in order to minimize the risk of becoming multiple hard
drives failure.
Fibre Channel / SAS Controller
It is connected to tape device, device expansion unit and iStorage. The controller varies by different device connected
Category
Product Name / Description
Part Number
Fibre Channel
Fibre Channel Controller (1ch)
Cavium QLogic, QLE2690
16Gb/s, Optical, PCIe 3.0 x8
NOTE:
- The controller is qualified with NEC Storage M series, OS support
WS2012R2 and WS2016
- The controller is qualified with NEC Storage T series, OS support
WS2012R2, WS2016 and RHEL7.3
N8190-165
Fibre Channel Controller (2ch)
Cavium QLogic, QLE2692
16Gb/s, Optical, PCIe 3.0 x8
NOTE:
- The controller is qualified with NEC Storage M series, OS support
WS2012R2 and WS2016.
- The controller is qualified with NEC Storage T series, OS support
WS2012R2, WS2016 and RHEL7.3
N8190-166
Fibre Channel Controller (1ch)
Broadcom, LPe31000
16Gb/s, Optical, PCIe 3.0 x8
NOTE:
- The controller is qualified with NEC Storage M series, OS support
WS2012R2 and WS2016.
- The controller is not qualified with NEC Storage T series
N8190-163
Fibre Channel Controller (2ch)
Broadcom, LPe31002
16Gb/s, Optical, PCIe 3.0 x8
NOTE:
- The controller is qualified with NEC Storage M series.
- The controller is not qualified with NEC Storage T series
N8190-164
Fibre Channel Controller (1ch)
Broadcom, LPe32000
32Gb/s, Optical, PCIe 3.0 x8
NOTE:
- The controller is qualified with NEC Storage M series.
- The controller is not qualified with NEC Storage T series
N8190-171
Fibre Channel Controller (2ch)
Broadcom, LPe32002
32Gb/s, Optical, PCIe 3.0 x8
NOTE:
- The controller is qualified with NEC Storage M series
- The controller is not qualified with NEC Storage T series
N8190-172
SAS
SAS Controller
12Gb/s SAS, ext. 8(SFF-8644 x2), PCIe 3.0 x8
NOTE:
- Support tape connection via Device Expansion Unit only
N8103-197
SAS Controller
LSI SAS9300-8e Host Bus Adapter
12Gb/s SAS, ext. 8(SFF-8644 x2), PCIe 3.0(x8)
NOTE:
- Support for connection to NEC Storage T series only.
- The controller is not qualified with NEC Storage the Storage M series or
Tape connection via Device Expansion Unit.
N8103-184
