CONTROL TEST PROCEDURE
automatically restart back from 0. Other digital inputs (Dry contact, Ext. Pause, etc.) show either 0 when the contact is
open or 1 when the contact is closed.
Note that the card number is set according to its jumpers regardless to its location (local or extension box).
• Perform a dry test. Using a magnet, get a pulse. Attach the magnet to get a pulse from the read of the cable.
• Verify the water, fertilizer and any auxiliary meters.

Delta pressure: 1 = ON, 0 = OFF
6.3 Analog Input
Analog inputs will show values from 0 to 1023.
Sensor type Description
pH sensor
pH = 0 – A/D = 205
pH = 7.0 – A/D = 615
pH = 14.0 – A/D = 1023
EC sensor
EC = 0 – A/D = 205
EC = 2.0 – A/D = 370
EC = 10.0 – A/D = 1024
Humidity sensor
RH% = 0 – A/D = 0
RH% = 50 – A/D = 308
RH% = 100 – A/D = 620
Temp sensor
T°C = 0 – A/D = 768
T°C = 25 – A/D = 489
T°C = 50 – A/D = 250
DIGITAL VALUE
Channel
Value
1
59
2
0
3
0
4
0
5
0
6
0
ANALOG INPUT
Channel
Value
pH
564
EC
345
Hum.
376
Temp1
511
Temp2
453
