SETUP MENU
11.5.2 EC/pH Transmitter Monitor & NMC-Junior Pro Correlation
Place the cursor on the relevant factor and use the left/right arrow keys to increase/decrease the factor until the values
displayed by the NMC-Junior Pro are equal to the values indicated on the EC/pH transmitter screen.
To ensure the measured values are stable it is recommended to immerse the sensor in calibration fluid when doing
this process.
Under normal operation conditions the correlation process should be done only when there are system changes, for
example when changing EC/pH sensors, nevertheless it is recommended to verify that the readings of the EC/pH
transmitter and of the NMC-Junior Pro are equal every time EC/pH calibration is performed, and adjust if required.
11.6 Sensors Logging
The Sensors Logging screen allows you to define which sensors should be logged.
To select an item move the cursor using the arrow keys and mark it using the ‘+/-‘ key. Selected items are marked with
√.

Note: When you change the sensors logging setup, the sensors history table resets and starts over; all sensors
data accumulated on the controller is lost.

Note: The NMC Junior Pro supports two temperature sensors only.
EC/pH CALIBRATION
Sensor
Value
Factor
EC 1
1.71
0.06
pH 1
2.36
0.07
EC 2
<NONE>
---
pH 2
<NONE>
---
Press < - > Arrows to Increase/Decrease
SENSOR LOGGING
Data to Collect
Yes/No
Temperature - Average
√
Temperature sensor - 1
√
Temperature sensor - 2
√
Temp sensor – 3 N/A
Temp sensor - 4 N/A
Temp sensor - 5 N/A
Temp sensor - 6 N/A
Temp sensor - 7 N/A
Temp sensor - 8 N/A
Humidity - Average
Press (+/-) To Select/Deselect
