NMC-Junior Pro Installation Manual
Page 16
3.3 Firmware Upgrade
The Bootloader application enables installing or updating the system firmware. The application is menu based and
simple to use and enables updating the firmware from an SD card.
Note: Verify that the card is in place before starting.
Note: Junior Pro supports up to 4 GB SD cards.
3.3.1 Accessing the Application
1. Press and hold the Left and Down arrow keys.
2. Turn on the unit.
In the screen that appears, enter the password: 38845.
Note: If you enter the wrong password, an error message appears and the program goes to the Main Screen.
Repeat the process.
3. Press Enter. The screen below appears.
Note: Hardware Test is used for quality control only.
3.3.2 Running the Application
Note: Pressing Exit or ESC takes you to the previous menu.
1. Select Hardware Firmware. The following screen appears (example only):
