NMC-JUNIOR PRO Installation Manual
91Page
SENSOR INSTALLATION AND DEFINITION

Note: Can wire 24VAC terminals of measuring box to 24VAC on the output terminals
15.2.1 Humidity Sensor Definition
15.3 Sensor and Cable Specifications
Sensor Type Measured Values Accuracy
Input
Range
Maximum Cable
Length
Cable Type
Temperature –
RTS-s
-20° to 50° C/ -4° to
122°F
0.3°C/0.54°F 30kOhm 500 meter (1640 feet)
2x0.5 mm² (20
AWG)
EC
0 to 10 mS (old
transmitters used
20 mS)
0.05 to 0.1 mS 4 – 20mA ---
3x0.5 mm² (20
AWG) Shielded
pH 0 - 14 0.1 4 – 20mA ---
RH – RHS-10 0 – 100%
±2% (10%-
90% RH),
±3.5% (90%-
100% RH)
0 – 3 VDC 300 meter (985 feet)
3x0.5 mm² (20
AWG)
