E2600 Controller-Drive Tray Installation Guide 114
3 Host Link 2 Fault Amber At least one PHY of the
four connections is
working, but another PHY
cannot establish the same
link to the device connected
to the Host In port
connector.
No link error has occurred.
4 Host Link 2 Active Green At least one of the four
PHYs in the IN port is
working, and a link exists
to the device connected to
the Host In connector.
A link error has occurred.
5 Ethernet Link
Active
Green The link is up. (The LED
blinks when there is
activity.)
The link is not active.
6 Ethernet Link Rate Green There is a 100BASE-T rate. There is a 10BASE-T rate.
7 ESM Expansion
Link Fault
Amber At least one of the four
PHYs in the Out port is
working, but another PHY
cannot establish the same
link to the Expansion Out
connector.
Normal status.
8 ESM Expansion
Link Active
Green At least one of the four
PHYs in the Out port is
working, and a link exists
to the device connected to
the Expansion Out
connector.
A link error has occurred.
9 ESM Service
Action Allowed
Blue The ESM can be removed
safely from the drive tray.
The ESM cannot be
removed safely from the
drive tray.
10 ESM Service
Action Required
Amber A fault exists within the
ESM. (This LED defaults
on at power up. This LED
turns off after the software
has completed its power up
self-test sequence.)
Normal status.
11 ESM Power Green 12V power to the ESM is
present.
Power is not present to the
ESM.
12 Seven-Segment
Tray ID
Green See note. Not applicable.
NOTE: For more information about the seven-segment tray IDs, see Things to Know – Seven Segment
Component Failure Identifications for the E2600 Controller-Drive Tray on page 123.
Location LED Color On Off
