Chapter 4: Drive Connection 93
Table 17 One CE7922 Controller Tray or CE7900 Controller Tray and DE6900
Drive Trays 3 and 4 with Drive-Side Trunking
Cable
Controller A Controller B Drive Tray 3
Ch1 Ch2 Ch3 Ch4 Ch5 Ch6 Ch7 Ch8 Top ESM Bottom ESM
8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 1A 1B 2A 2B 1A 1B 2A 2B
1XX
2XX
Cable
Drive Tray 3 Drive Tray 4
Top ESM Bottom ESM Top ESM Bottom ESM
1A 1B 2A 2B 1A 1B 2A 2B 1A 1B 2A 2B 1A 1B 2A 2B
3X X
4X X
5X X
6X X
Cable
Controller A Controller B Drive Tray 4
Ch1 Ch2 Ch3 Ch4 Ch5 Ch6 Ch7 Ch8 Top ESM Bottom ESM
8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 1A 1B 2A 2B 1A 1B 2A 2B
7X X
8X X
To Next Page
