Chapter 2: Product Compatibility 37
Drive Tray
Information by
Model
The following tables lists drive tray specifications that might affect your topology.
Make sure that your planned topology is compatible with these specifications and
restrictions.
NOTE When you mix different types of drive trays, you must consider the total
number of drives that are available in the final configuration of the storage array. Your
configuration must meet both the limit on the total number of drives and the limits on
the number of drive trays of a given model.
NOTE The maximum number of drives and the maximum number of drive trays for
a redundant pair of channels is the same as for a single non-redundant channel.
Table 3 Specifications for Non-SAS Drive Trays
The E5400 controller-drive tray models are: E5412, E5424, and the E5460. For
configurations of the E5400 with InfiniBand host connections, the total number of
drives in the storage array, including the drives in the controller-drive tray and those
in all of the attached drive trays, must not exceed 240. For all other configurations of
the E5400, the total number of drives in the storage array, including the drives in the
controller-drive tray and those in all of the attached drive trays, must not exceed 384.
For all configurations of the E5400, the total number of trays in the storage array,
including the controller-drive tray and all of the attached drive trays, must not exceed
16. The maximum number of drive trays listed in the following table is based on a
storage array where the controller-drive tray is fully populated with drives.
Model Port Speed Drives per Tray
Maximum Number of Drive
Trays per Channel
DE6900 drive tray 4 Gb/s 60 2
FC4600 drive tray 4 Gb/s 16 7
FC2610 drive tray 2 Gb/s 14 8
FC2600 drive tray 2 Gb/s 14 8
AT2655 drive tray 2 Gb/s 14 8
