Host Interface
Connections
The CE7900 controller tray connects to hosts through one or two host interface cards
(HICs). The CE4900 controller-drive tray has built-in (base) Fibre Channel storage
array (FC) connectors for host connections and might also have an optional HIC. The
E2600 controller-drive tray and the E2660 controller-drive tray have built-in (base)
SAS connectors for host connections and might also have an optional HIC. The
E5400 controller-drive trays (E5412, E5424, and E5460) have built-in (base) Fibre
Channel, and might also have an optional HIC for Fibre Channel connections or
InfiniBand connections. All other supported controller trays and controller-drive trays
connect through built-in ports.
Table 1 Types of Host Port Configurations and HICs for Controller Trays and
Controller-Drive Trays
Controller Type Base Ports HIC 1 HIC 2
CE7900 None Quad 4-Gb/s FC,
Quad 8-Gb/s FC,
Dual 1-Gb/s iSCSI,
or
Dual 10-Gb/s iSCSI
None,
Quad 4-Gb/s FC,
Quad 8-Gb/s FC,
Dual 1-Gb/s iSCSI,
or
Dual 10-Gb/s iSCSI
E5412, E5424, and
E5460
Quad 8-Gb/s FC None,
Quad 8-Gb/s FC, or
Dual 40-Gb/s
InfiniBand
None
CE4900 Dual 8-Gb/s FC None,
Dual 8-Gb/s FC, or
Dual 1-Gb/s iSCSI
None
E2600
E2660
Dual 6-Gb/2 SAS None,
Dual 6-Gb/2 SAS,
Quad 8-Gb/s FC,
Quad 1-Gb/s iSCSI,
or
Dual 10-Gb/s iSCSI
None
