Chapter 4: Drive Connection 59
4
Drive Connection
This chapter provides examples of connecting between a controller tray or a
controller-drive tray and the environmental services modules (ESMs) of one or more
expansion drive trays. This chapter also shows potential combinations of these
products in storage array configurations.
NOTE Each example in this chapter provides redundant access to each drive.
See the topics under "Component Locations"on page 153 for drive port locations on
the specified controller tray or controller-drive tray and drive tray models that you are
installing.
Refer to the section that applies to the controller tray or controller-drive tray to which
you are connecting the drive trays.
