Chapter 1: Cabling Concepts and Best Practices 21
Single-Controller
Topologies and
Dual-Controller
Topologies
If you are creating a topology for a controller tray or a controller-drive tray that
contains only one controller, you can attach only drive trays that contain a single
environmental services module (ESM). Do not attach a drive tray that contains two
ESMs to a single-controller controller tray or a single-controller controller-drive tray.
Copper Cables and
Fiber-Optic Cables
You can use a combination of copper cables and fiber-optic cables to connect the
drive trays to a controller tray or to a controller-drive tray. However, when a drive
tray communicates with the controller tray (or the controller-drive tray) indirectly,
through another drive tray, the connections between the drive tray and the controller
tray (or the controller-drive tray) and between the two drive trays must use the same
type of cable. Fiber-optic cables are required for host connections.
E5424 Controller-Drive Tray
High Performance Coomputing
Configuration
Up to 15 per
controller-drive tray
when the
controller-drive tray
contains 24 drives
Up to nine per
controller-drive tray
when the
controller-drive tray
contains 24 drives
Up to three per
controller-drive tray
when the
controller-drive tray
contains 24 drives
E5412 Controller-Drive Tray
High Performance Coomputing
Configuration
Up to 15 per
controller-drive tray
when the
controller-drive tray
contains 12 drives
Up to nine per
controller-drive tray
when the
controller-drive tray
contains 12 drives
Up to three per
controller-drive tray
when the
controller-drive tray
contains 12 drives
E2660 Controller-Drive Tray Not supported Not supported Up to two per
controller-drive tray
E2624 Controller-Drive Tray Up to 15 per
controller-drive tray
Up to seven per
controller-drive tray
Not supported
E2612 Controller-Drive Tray
E2612 Controller-Drive Tray
Up to 16 per
controller-drive tray
Up to eight per
controller-drive tray
Not supported
DE1600 Drive Trays DE5600 Drive Trays DE6600 Drive Trays
