100
Table 22 One CE6998 Controller Tray and Four Drive Trays
NOTE If you have drive trays with inverted ESM canisters, see "ESM Canister
Arrangements" on page 69.
Drive Channel
Connection Point Connection Point
Tray or Component
Port Number and
Location
Tray or Component
Port Number and
Location
1 Controller A 4 Drive tray 1 Left ESM, port B
Controller A 3 Drive tray 2Left ESM, port B
2 Controller A 2 Drive tray 3 Left ESM, port B
Controller A 1 Drive tray 4Left ESM, port B
3 Controller B 1 Drive tray 1 Right ESM, port B
Controller B 2 Drive tray 2 Right ESM, port B
4 Controller B 3 Drive tray 3 Right ESM, port B
Controller B 4 Drive tray 4 Right ESM, port B
