110
The following figure shows how the cabling pattern can be continued for additional
drive trays until the 15 drive tray limit or the limit on the total number of drives in the
storage array is reached. The figure uses the schematic representation for DE1600
drive trays or DE5600 drive trays. However, DE6600 drive trays can be included in
the storage array as long as the same cabling pattern, connecting SAS expansion ports
to SAS In ports, is followed.
NOTE The cabling pattern is independent of the physical location of the trays in the
cabinet. If the storage array includes DE6600 drive trays, install those drive trays
beginning from the bottom of the cabinet so that the cabinet does not become
top-heavy. A top-heavy cabinet has a greater risk of falling over.
