Chapter 4: Drive Connection 61
Table 1 Redundant Path Pairs on the CE7900 Controller Tray and the CE7922
Controller Tray
Drive Ports on
Controller A
Drive Channels
on Controller A
Ports on
Controller B
Drive Channels
on Controller B
Port 8 Channel 1 Port 1 Channel 5
Port 7 Channel 1 Port 2 Channel 5
Port 6 Channel 2 Port 3 Channel 6
Port 5 Channel 2 Port 4 Channel 6
Port 4 Channel 3 Port 5 Channel 7
Port 3 Channel 3 Port 6 Channel 7
Port 2 Channel 4 Port 7 Channel 8
Port 1 Channel 4 Port 8 Channel 8
