NETGEAR GS108T - ProSafe - Gigabit Smart Switch User Manual

GS108T Smart Switch Software Administration Manual
5-18 Configuring QoS and Security
v1.0, December 2007
Port Security
The Port Security screen lets you to configure port learning for unknown source MAC address
packets. If the learning mode is disabled, you can specify an action that must be taken for unknown
source MAC address packets. To configure port security:
1. Select Security > Traffic Control > Port Security. A screen similar to the following displays.
.
2. You can make changes to the port security setting for an individual port, for a group of ports,
or for all ports simultaneously:
• To change the port security setting for an individual port, select the check box to the left of
its port number, and then select the learning mode and action.
• To change the port security setting for a group of ports, select the check boxes to the left of
their port numbers, and then select the learning mode and action.
• To change the port security setting for all ports simultaneously, select the check box at the
top of the column of check boxes, and then select the learning mode and action.
Figure 5-12
Note: You can also enter the interface number (that is, the port number) in the GO
TO INTERFACE field, and then click GO.

NETGEAR GS108T - ProSafe - Gigabit Smart Switch Specifications

General

Model	GS108T
Product Line	ProSafe
Form Factor	Desktop
Power Supply	External Power Adapter
Layer	Layer 2
Switching Capacity	16 Gbps
Forwarding Rate	11.9 Mpps
PoE	No
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Ports	8 x 10/100/1000
Management	Smart
MAC Address Table Size	8K entries
Remote Management Protocol	SNMP, RMON, HTTP, HTTPS
Features	VLAN support, QoS, IGMP snooping
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 to 50°C (32 to 122°F)
Certifications	CE, FCC
Jumbo Frame Support	Supported, up to 9, 000 bytes
