GS108T Smart Switch Software Administration Manual
Monitoring, Maintenance, and Help 6-11
v1.0, December 2007
• Info. Specifies whether informational messages are logged. Select one of the following
values from the drop-down list:
– On. Specifies that informational messages are logged.
– Off. Specifies that informational messages are not logged.
• Debug. Specifies whether debug messages are logged. Select one of the following values
from the drop-down list:
– On. Specifies that debug messages are logged.
– Off. Specifies that debug messages are not logged.
3. Click Apply to confirm any settings changes.
Memory Logs
The Memory Logs screen displays the messages that are logged in the RAM memory in the way
that you specified in the previous section:
1. Select Monitoring > Log > Memory Logs. A screen similar to the following displays.
Under Memory Logs, the following fields are displayed:
• No. Shows the entry number for the log.
• Index. Shows the global sequence number for the log.
• Time. Shows the time when the log is recorded.
• Level. Shows the severity of the log.
• Message. Shows the detailed description of the log entry.
Figure 6-7

NETGEAR GS108T - ProSafe - Gigabit Smart Switch Specifications

General

Model	GS108T
Product Line	ProSafe
Form Factor	Desktop
Power Supply	External Power Adapter
Layer	Layer 2
Switching Capacity	16 Gbps
Forwarding Rate	11.9 Mpps
PoE	No
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Ports	8 x 10/100/1000
Management	Smart
MAC Address Table Size	8K entries
Remote Management Protocol	SNMP, RMON, HTTP, HTTPS
Features	VLAN support, QoS, IGMP snooping
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Operating Temperature	0 to 50°C (32 to 122°F)
Certifications	CE, FCC
Jumbo Frame Support	Supported, up to 9, 000 bytes
