NETGEAR JWNR2000v2 User Manual

12 | Chapter 1. Hardware Setup
NETGEAR N300 Wireless Router JWNR2000v2 User Manual
Cable Your Router
The installation guide that came in the box has a cabling diagram on the first page. This
section walks you through cabling with detailed illustrations.
To connect the router, the computer, and the modem:
1. Turn off and unplug your broadband modem.
2. Locate the cable (A) that connects your computer to the modem. Disconnect the cable at the
modem end only (B). You will connect it to the router later.
A
B
Figure 4. Disconnect the modem end of the Ethernet cable
3. Connect the blue Ethernet cable (C) that came with the router to the Internet (WAN) port on
the router, and to the Ethernet port on your broadband modem. The cable and the Internet
port label are color coded.
C
D
Figure 5. Use the Ethernet cable to connect the modem to the router

NETGEAR JWNR2000v2 Specifications

General

Brand	NETGEAR
Model	JWNR2000v2
Category	Wireless Router
Language	English
