NETGEAR N600 User Manual

Hardware Setup
12
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router DGND3700v2
Back Panel
The back panel has the Power On/Off button and port connections shown in the figure:
4. Gigabit-Ethernet WAN port for connecting to external
6. Power On/Off button
2. USB port
5. AC power adapter input
1. ADSL line
3. Gigabit-Ethernet LAN ports
cable or fiber modem
Figure 3. Back panel port connections
Viewed from top to bottom, the back panel contains the following elements:
1. RJ-11 asynchronous DSL (ADSL) port for connecting the wireless modem router to an
ADSL line
Note: An ADSL port is capable of sending data over an ADSL line at one
speed and receiving it at another speed.
2. USB port for connecting USB storage devices like flash drives or hard drives
3. Four Gigabit-Ethernet RJ-45 LAN ports for cabling the wireless modem router to the local
comput
ers
4. One Gigabit-Ethernet WAN port for connecting the wireless modem router to a fiber or
cab
le modem

NETGEAR N600 Specifications

General

Wi-Fi	Yes
Modulation	CCK, OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	40-bit WEP, 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	600 Mbit/s
Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Internal	No
Certification	FCC, CE
Component for	PC/Laptop
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional

Weight and Dimensions

Depth	28 mm
Width	87 mm
Height	14 mm
Weight	19 g
