Table 9. LAN LED
Icon LED Activity Description
Solid green A LAN port has detected an Ethernet link with a device.
Blinking green Data is being transmitted or received.
Off No link is detected on these ports.
Table 10. Power On/Off LED
Icon LED Activity Description
Solid green Power is supplied to the router.
Solid red POST (power-on self-test) failure or a device malfunction has occurred.
Off Power is not supplied to the router.
Restore Factory
Settings
Light blinks momentarily when the Restore Fa
ctory Settings button on the
bottom of the unit is pressed for six seconds. The Power LED then blinks
red three times when the Restore Factory Settings button is released and
then turns green as the gateway resets to the factory defaults.
Hardware Setup
16
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router DGND3700v2
Position Your Wireless Router
The wireless modem router lets you access your network from virtually anywhere within the
operating range of your wireless network. However, the operating distance or range of your
wireless connection can vary significantly depending on the physical placement of your
router. For example, the thickness and number of walls the wireless signal passes through
can limit the range. For best results, place your router:
• Near
the center of the area where your computers and other devices operate, and
prefe
rably within line of sight to your wireless devices.
• So it is accessible to an
AC power outlet and near Ethernet cables for wired computers.
• In an elevated location such as a high shelf, ke
eping the number of walls and ceilings
between the wireless modem router and your other devices to a minimum.
• Away from electrical devices that are potential so
urces of interference, such as ceiling
fans, home security systems, microwaves, computers, or the base of a cordless phone or
2.4 GHz cordless phone.
• A
way from any large metal surfaces, such as a solid metal door or aluminum studs. Large
exp
anses of other materials such as glass, insulated walls, fish tanks, mirrors, brick, and
concrete can also affect your wireless signal.
Note: The DGND3700 should be put in a vertical position only.
