NETGEAR N600 User Manual

Hardware Setup
18
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router DGND3700v2
Two-Line ADSL Microfilter (Included)
Use an ADSL microfilter with a built-in splitter when there is a single wall outlet that provides
connectivity for both the wireless modem router and your telephone equipment. Plug the
ADSL microfilter into the wall outlet, plug your phone equipment into the jack labeled Phone,
and plug the wireless modem router into the jack labeled ADSL.
Plugs into the ADSL line
Figure 6. Two-line ADSL microfilter with built-in splitter
Summary
• One-line ADSL microfilter (not included). Use with a phone or fax machine.
• Splitter (not included). Use with a one-line ADSL microfilter to share an outlet with a
phon
e and the wireless modem router.
• Two-line ADSL microfilter with built-in splitter (included).
Use to share an outlet with a
phone and the wireless modem router.

NETGEAR N600 Specifications

General

Wi-Fi	Yes
Modulation	CCK, OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	40-bit WEP, 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	600 Mbit/s
Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Internal	No
Certification	FCC, CE
Component for	PC/Laptop
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional

Weight and Dimensions

Depth	28 mm
Width	87 mm
Height	14 mm
Weight	19 g
