NETGEAR N600 User Manual

Genie Basic Settings
36
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router DGND3700v2
• Does your wireless device or computer show up on the Attached Devices screen? If it
does, then it is connected to the network.
• If you
are not sure what the network name (SSID) or password is, look on the label on
the bottom of your wireless modem router.
Wireless Settings Screen Fields
Region. The location where the wireless modem router is used. Select from the countries in
the list. Note that in the United States, the region is fixed to United States and is not
changeable.
Wireless Network
Note: These settings apply separately to the 2.4 GHz b/g/n and 5 GHz a/n
bands.
Name (SSID). The SSID is also known as the wireless network name. Enter a 32-character
(maximum) name in this field. This field is case-sensitive. The default SSID is randomly
generated, and NETGEAR strongly recommends that you do not change this.
Channel.
This setting is the wireless channel used by the gateway. Enter a value from 1
through 13. (For products in the North America market, only Channels 1 through 11 can be
operated.) Do not change the channel unless you experience interference (shown by lost
connections or slow data transfers). If this happens, experiment with different channels to see
which is the best.
Mode. Up to
130 Mbps is the default and allows 802.11n and 802.11g wireless devices to join
the network. g & b supports up to 54 Mbps. The 300 Mbps setting allows 802.11n devices to
connect at this speed.
Enable SSID Broadcast. This settin
g allows the wireless modem router to broadcast its
SSID so wireless stations can see this wireless name (SSID) in their scanned network lists.
This check box is selected by default. To turn off the SSID broadcast, clear the Enable SSID
Broadcast check box, and click Apply.
Enable Wireless Isolation.
If this check box is selected, then wireless clients (computers or
wireless devices) that join the network can use the Internet, but cannot access each other or
access Ethernet devices on the network.
Security Options Settings
Note: These settings apply separately to the 2.4 GHz b/g/n and 5 GHz a/n
bands.

NETGEAR N600 Specifications

General

Wi-Fi	Yes
Modulation	CCK, OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	40-bit WEP, 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	600 Mbit/s
Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Internal	No
Certification	FCC, CE
Component for	PC/Laptop
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional

Weight and Dimensions

Depth	28 mm
Width	87 mm
Height	14 mm
Weight	19 g
