NETGEAR N600 User Manual

Hardware Setup
13
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router DGND3700v2
Note: You can use either the ADSL or Gigabit-Ethernet port for WAN
connectivity.
5. AC power adapter input
6. Power On/Off
button
Front Panel
The wireless modem router front panel has the 10 status LEDs, icons, and ports shown in the
figure. Note that the Wireless and WPS icons are buttons.
Power
LAN ports
DSL
Internet
5 GHZ wireless
USB port
Wireless On/Off button
WPS On/Off button
2.4 GHz wireless
USB
Figure 4. Front panel LEDs
The following tables describe the LEDs, icons, and buttons on the front panel from top to
bottom.

NETGEAR N600 Specifications

General

Wi-Fi	Yes
Modulation	CCK, OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	40-bit WEP, 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	600 Mbit/s
Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Internal	No
Certification	FCC, CE
Component for	PC/Laptop
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional

Weight and Dimensions

Depth	28 mm
Width	87 mm
Height	14 mm
Weight	19 g
