NETGEAR N600 User Manual

Table 1. WPS button and LED
Icon LED Activity Description
Solid green Indicates that wireless security has been enabled.
Blinking green WPS-capable device is connecting to the device.
Off WPS is not enabled. For information about the use of
this button, see Wi-Fi
Protected Setup (WPS) Method on page 26.
Table 2. Wireless button
Icon Description
For information about the use of this button, see Wireless Connectivity on page 126.
Table 3. USB port
Icon Description
USB port for connecting USB storage devices like flash drives or hard drives.
Table 4. Internet LED
Icon LED Activity Description
Solid green You have an Internet connection. If this connection is dropped due to an
idle time-out but the connection is still present, the light stays green. If the
Internet connection is dropped for any other reason, the light turns off.
Solid red The Internet (IP) connection failed. See Cannot Access the Internet on
page 123 for troubleshooting information.
Blinking green Data is being transmitted over the Internet connection.
Off No Internet connection is detected or
the
device is in bridge mode (an
external device handles the ISP connection).
Hardware Setup
14
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router DGND3700v2

NETGEAR N600 Specifications

General

Wi-Fi	Yes
Modulation	CCK, OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	40-bit WEP, 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	600 Mbit/s
Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Internal	No
Certification	FCC, CE
Component for	PC/Laptop
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional

Weight and Dimensions

Depth	28 mm
Width	87 mm
Height	14 mm
Weight	19 g
