NETGEAR N600 User Manual

Table 5. DSL LED
Icon LED Activity Description
Solid green You have an ADSL connection. In technical terms, the ADSL port is
synchronized with an ISP’s network-access device.
Blinking green Indicates that the wireless modem router is n
egotiating the best possible
speed on the ADSL line.
Off The unit is off or there is no IP connection.
Table 6. 5 GHz Wireless LED
Icon LED Activity Description
Solid blue There is wireless connectivity.
Blinking blue Data is being transmitted or received over the 5 GHz wireless link.
Off There is no wireless connectivity. You can still plug an Ethernet cable into
one
of the LAN ports to get wired connectivity.
Table 7. 2.4 GHz Wireless LED
Icon LED Activity Description
Solid green There is wireless connectivity.
Blinking green Data is being transmitted or received over the 2.4 GHz wireless link.
Off There is no wireless connectivity. You can still plug an Ethernet cable into
one
of the LAN ports to get wired connectivity.
Table 8. USB LED
Icon LED Activity Description
Solid green A USB port has detected a USB device.
Blinking green Data is being transmitted or received.
Off No link is detected on these ports.
Hardware Setup
15
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router DGND3700v2

NETGEAR N600 Specifications

General

Wi-Fi	Yes
Modulation	CCK, OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	40-bit WEP, 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	600 Mbit/s
Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Internal	No
Certification	FCC, CE
Component for	PC/Laptop
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Windows operating systems supported	Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Professional

Weight and Dimensions

Depth	28 mm
Width	87 mm
Height	14 mm
Weight	19 g
