Use VLANS for Traffic Segmentation
53
ProSAFE Gigabit Web Managed (Plus) Switches
WARNING:
Do not remove all ports from PVID 1, which is the management PVID.
If you remove all ports from PVID 1, you cannot access the switch for
management. In such a situation, to recover access to the switch,
you must reset the switch to its factory defaults settings.
9. Click the Apply button.
Your settings are saved.
Use the ProSAFE Plus Utility to Assign a PVID to Ports
To assign a PVID to one or more ports:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that is
off-network using an Ethernet cable.
2. Double-click the ProSAFE Plus Utility icon.
The Switch Selection page displays a list of Web Managed (Plus) switches that it
discovers on the local network.
3. Select the switch.
If you do not see the switch, click the REFRESH button.
4. Click the APPLY button.
You are asked to enter the password for the switch.
5. Enter the switch’s password in the password field.
The switch’s default password is password.
The Switch Status page displays.
6. Select VLAN > 802.1Q > Advanced > PVID.
You can select Port PVID only if you already enabled the advanced 802.1Q VLAN option
(see Create 802.1Q-Based VLANs in an Advanced Configuration on page 46).

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR ProSAFE GS108Ev3 and is the answer not in the manual?

NETGEAR ProSAFE GS108Ev3 Specifications

General IconGeneral
ModelGS108Ev3
CategorySwitch
Switching Capacity16 Gbps
Forwarding Rate11.9 Mpps
MAC Address Table Size4K
Jumbo Frame Support9, 216 bytes
VLAN SupportYes
QoSYes
Power over Ethernet (PoE)No
Fanless DesignYes
Power SupplyExternal power adapter
Ports8 Gigabit Ethernet ports
ManagementWeb-based management
Energy Efficient Ethernet (EEE)Yes
Operating Temperature0° to 40°C (32° to 104°F)
Storage Temperature-20° to 70°C (-4° to 158°F)
Humidity90% maximum relative humidity, noncondensing
Dimensions6.22 x 4.02 x 1.10 in (158 x 102 x 28 mm)
