NetWave NW6010 - Part 1: Installation Manual; Specification Sheet

Page 24/ 191
Part 1: Installation manual
1. Specification sheet
Unit
Type
Number
Dimensions
(mm)
(H x D x W)
Weight
(kg)
Specifications
Core module
NW6000
484 x 450 x 45
16.5
(incl.
batteries)
- PSU (110/230 Vac, 50/60 Hz) / 100
Watt
- Includes mains filter
- Built-in UPS
- 10 port switch (8 x PoE, 2 x Non-PoE)
- CPU unit with min. 30 days storage
Bulkhead
mount frame
and cover
NW6900
744 x 464 x 115
11
(excl. core
module)
- Internal wiring
- External RJ45 connector bank
Bridge
Control Unit
NW6010
150 x 100 x 134
1.8
- Powered from Core module thru PoE
- 4” touch color screen
- Panel mounted with frame (IP20)
Microphone
(Internal &
External)
NW6030
70 x 83 x 83
0.4
- Powered from Audio Hub
- Analogue
- LED identification light
Audio Hub
NW6031
35 x 152 x 106
0.35
- Powered using PoE
- Bulkhead mounted
VHF
Interface
NW6060
180 x 87 x 47
0.5
- Powered using PoE
- 2 line-in
- Interface for microphones
- Bulkhead mounted (IP20)
Hardened
FRM
NW6860
411 x 311
27.5
- Powered thru PoE from core module
- Deck mounted protective capsule for
48 days (IP68)
- 90 day under water locator beacon
Float Free
FRM
NW6880
533 x 240 x 218
5.4
- Powered thru PoE from core module
- Includes 3m maritime CAT-6 cable
- Bulkhead mounted in protective
cover for 48 days storage (IP67)
Interface
Module
NW64900
182 x 232 x 436
2 ~ 3
(subject to 1
- 7 module
interfaces)
- Powered thru PoE from core module
- DIN rail mounted interface
- NMEA (up to 38k4) (multiple 8 port)
- Digital sensors (multiple 8 port)
- Analogue sensors (multiple 4 port)
- Additional 24 Vdc power Input/Output
Video
Interface
NW6044
38 x 240 x 184
1
- For non-networked video
- 4 channels video
- Bulkhead/DIN rail mounting
- 24 VDC / 12 watt
• Orolia Netwave recommends maritime CAT-6 ethernet cable for connecting all units to
the core module switch.
• Complete system runs from 110 (60Hz) to 230 Vac (50 Hz) through the core module.
