8. Save the file.
9. Click the Load <VidChanX.ini> file.
10. Choose the <VidChanX.ini >file which was altered and saved in Step 5 above.
The above procedure provides an image in the Video Config Suite application that can be properly
configured in accordance with paragraph ‘Video Configuration Suite (VCS2) Application’.
If the HSync value was obtained via the Video Config Suite application, it is recommended
that the installer carefully check to make sure that the VCO, CPMP, and Phase settings are
correct for the captured image.
Save Settings (REMEMBER!)
Once the image has been adjusted correctly, click the Configuration tab page and click Save
<VidChanX.ini> file to save the settings.
10.27 Info Tab
Selecting the Info tab of the Video Configuration Utility opens the Info page. It provides statistics
on the capture image.
The Histogram window displays the histogram for the image.
The Cross-Section window (indicated by the dashed red line) shows a graph of the current cross-
section of the image, as well as minimum and maximum values of Red, Green, and Blue on the
cross-section line.
Channel Selection lets the user enable or disable which color channels are selected or
deselected. For example, the installer can disable Green.
The Status controls at the bottom of the page enable the installer to display information about
the image such as:
▪ BPP (bits per pixel)
▪ Image size
▪ Cursor position
▪ RGB value at the cursor position
▪ Viewing bounds
▪ Zoom level
