10.3 Power supply
The NW6044 requires an external 24Vdc power supply. The ship’s 24Vdc (emergency) power
supply and be used if desired. The DC power supply connector sits next to the Ethernet port on
the unit.
10.4 Connections
The Video Module is connected to the CM (core module) via an Ethernet cable.
Video Module Front Panel Connection
Connector
Description
10-30 VDC+
Input power positive (ship)
10-30 VDC-
Input power negative (ship)
RJ45 connector
Ethernet Connection to CM
Table 9.4. A - Video Module Front Panel Connection
Video Module Back Panel Connection
Connector
Description
Video1
Channel 1 Video DB-15HD input
Video2
Channel 2 Video DB-15HD input
Video3
Channel 3 Video DB-15HD input
Video4
Channel 4 Video DB-15HD input
Table 9.4.B - Video Module Back Panel Connection
In cases where the video module is not co-located with its video source the following video cable
types are recommended to bridge the distance between video sources and the video module:
1. 75-ohm Coaxial cable - RG11 for cable lengths > 30m
a. Reference: FLAMEX RG11AU
b. Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
c. Approval: ABS, BV, DNV, GL, LRS or RINA
2. 75-ohm Coaxial cable – RG6 for cable lengths < 30m
a. Reference: FLAMEX RG11AU
b. Type: Marine Grade – Low Smoke, Halogen Free, Fire Retardant
c. Approval: ABS, BV, DNV, GL, LRS or RINA
3. 75-ohm Coaxial cable – RG-59 for cable lengths < 10m
The above cables must be converted to a 15-Pin Male VGA Plug at the Video Module end using
a manufactured BNC to VGA cable assembly and possibly BNC F/F Unions to connect to the
Video Module input.
