MAIN POWER
230V AC
3A
3 x 2,5 mm2
ALARM
(RELAY
, NC)
to Bridge Alarm
Management System
(SR.5)
FIXED & LOCKED
INTERNAL
INTERCONNECT
- do not remove
-
CMF
1.1 - to Fixed Capsule Final Recording Medium
(drawing N
6-1.3) (SR.1)
CMF
1.2 - to Free Floating Final Recording Medium
(drawing N
6-1.5) (SR.1)
CMF
1.3 - to Bridge Control Unit
/ Bridge Display Unit
(drawingN
6-1.4)
(SR.1)
CMF
1.4 - to DAQ Data Acquisition Modular System
(drawing N
6-1.8) (SR.1)
CMF
1.5 - (optional
) sensor data i
.e. DAQ
/ IEC61162
-450 (LWE) / IEC62338
(PoE 802.3af)
CMF
1.6 - (optional
) sensor data i
.e. DAQ
/ IEC61162
-450 (LWE) / IEC62338
(PoE 802.3af)
CMF
1.7 - (optional
) sensor data i
.e. DAQ
/ IEC61162
-450 (LWE) / IEC62338
(PoE 802.3af)
CMF
1.8 - (optional
) sensor data i
.e. DAQ
/ IEC61162
-450 (LWE) / IEC62338
(PoE 802.3af)
CMF
1.9 INTERNAL INTERCONNECT to CMF
1.11
(SR.1)
CMF
1.10 optional to bridge network
/ DATA port
(IEC61196
-1:2013
(SR.3)
CMF
1.11 INTERNAL INTERCONNECT to CMF
1.9
CMF
1.12 DATA
(IEC61996
-1:2013
) or to bridge network
(fail-over)
CMF
1.1-1.10
CMF
1.11-1.12
NOTE
: Ports CMF
1.1-1.8 are (auto sensing
) PoE 802.3af compliant and may also be used without PoE requirement
Weight Color IP rating
16,5 kg grey IP20
