16. Once the image is properly interlaced, it can now be adjusted to finish correcting the
image.
Figure 10.18.5 – Incorrectly Interlaced image
To achieve the optimal image capture. After properly interlacing the image, the installer may
need to adjust the Sizing page’s Horizontal/Vertical offsets, Width and Height dimensions.
Figure 10.18.6 - Properly Interlaced Image
